X-Flex Hi-Volt™
7500 Volts
 |
CONDUCTORS
8 AWG - 4/0 AWG Stranded Tinned Copper per ASTM B-33 STRANDING
Tinned Copper Stranding STANDARD
UL Standard 758 - Style 3499 INSUlATION
POE Color-Coded Ethylene Propylene Diene Monomer (EPDM). VOlTAGE
7500 Volts TEMPERATURE
150°C (min temp -40°C) STANDARD COLORS
Black OPTIONS
Additional colors and stripes available as well as other copper constructions. Minimums may apply. |
| Cobra Part Number |
Size | Stranding |
Insulation | Nominal OD | UL Style |
|---|---|---|---|---|---|
| AWG | IN | IN | |||
| MX87500V-07 | 8 | 7 X 12/27 TC LHL | 0.112 | 0.431 | AWM 3499 |
| MX67500V-07 | 6 | 7 X 12/25 TC LHL | 0.112 | 0.473 | AWM 3499 |
| MX47500V-07 | 4 | 7 X 19/25 TC LHL | 0.112 | 0.526 | AWM 3499 |
| MX27500V-07 | 2 | 7 X 95/30 TC Unilay | 0.112 | 0.560 | AWM 3499 |
| MX1/07500V-07 | 1/0 | 7 X 37/24 TC Unilay | 0.112 | 0.684 | AWM 3499 |
| MX2/07500V-07 | 2/0 | 7 X 37/23 TC Unilay | 0.112 | 0.735 | AWM 3499 |
| MX3/07500V-07 | 3/0 | 19 X 88/30 TC Unilay | 0.112 | 0.740 | AWM 3499 |
| MX4/07500V-07 | 4/0 | 7 X 37/21 TC Unilay | 0.112 | 0.854 | AWM 3499 |
COBRA WIRE & CABLE AWG SIZE E NUMBER AWM 3499 150°C 7500 V EP ROHS COMPLIANT MADE IN USA
